• Embedded processor
• H.264+/H.264 dual-stream video compression
• Support HDCVI/AHD/TVI/CVBS/IP video inputs
• Max 8 channels IP camera inputs, each channel up to 5MP
• Max 96Mbps Incoming Bandwidth
• Smart Search and Intelligent Video System
Technical Specifications:
System
• Main Processor Embedded Processor
• Operating System Embedded LINUX
Display
• Interface 2 HDMI, 1 VGA, 1 TV
• Resolution 1920×1080, 1280×1024, 1280×720, 1024×768
Multi-screen Display
• 1/4/8/9/16/25
• OSD Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Video Detection and Alarm
• Trigger Events Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips
• Video Detection Motion Detection, MD Zones: 396 (22 × 18), Video Loss,Tampering and Diagnosis
• Alarm input 16
• Relay Output 6
• Tracking Trigger Event N/A
Playback and Backup
• Playback 1/4/9/16
• Search Mode Time /Date, Alarm, MD and Exact Search (accurate to second), Smart search
• Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera,Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom
• Backup Mode USB Device/Network
Storage
• Internal HDD 8 SATA Ports, up to 8TB capacity for each disk
• HDD Mode Single
• eSATA 1 Port
Auxiliary Interface
• 4 USB Ports (2 USB 2.0 , 2 USB 3.0)
• RS232 1 port, for PC communication & Keyboard
• RS485 1 Port, for PTZ Control
Third-party Support
• Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more
Audio and Video
• HDCVI Camera Input 16 Channel
• IP Camera Input 16+8 Channel, each channel up to 5MP
• Audio In/Out 16 Audio In, 1 Audio Out
• Two-way Talk 1 Mic In, 1 Mic Out, BNC
Recording
• Compression H.264+/H.264
• Resolution 1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF
Record Rate
• Main stream: 1080P(1~15fps) 1080N/720P/960H/D1/HD1/BCIF/CIF/QCIF (1~25/30fps)
• Sub steram:D1/CIF/QCIF(1~15fps)
• Bit Rate 1Kbps ~ 6144Kbps Per Channel
Record Mode
• Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss,Tampering), Alarm, Stop
• Record Interval 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec
Network
• Interface 8CH: 2 RJ-45 Port (1000M)
Network Function
• HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P, IP Search (Support Dahua IP camera,DVR, NVS, etc.)
• Max. User Access 128 users
• Smart Phone iPhone, iPad, Android
• Interoperability ONVIF 2.4.1, CGI Conformant
Electrical
• Power Supply AC100V-240V, 50/60Hz
• Power Consumption <35W (Without HDD)
Environmental
• Operating Conditions -10°C ~ +55°C (+14°F ~ +131°F), 86 ~ 106kpa
• Storage Conditions 0°C ~ +50°C (+32°F ~ +122°F), 0 ~ 90% RH
Construction
• Dimensions 2U, 440mm×455mm×95mm (17.3" x 17.9" x 3.7")
• Net Weight 6.5kg (14.32 lb) (without HDD)
• Gross Weight 9.8kg (21.6lb)
• Installation Desktop installation/Rack-mounted
